Single Plate Spring Loaded Stainless Steel JIS Valve , Wafer Check Valve With Lift Type Design

Product Categories
TEKO Industry Co., Limited
Contact Now

Single Plate Spring Loaded Stainless Steel JIS Valve , Wafer Check Valve With Lift Type Design

Brand Name : TEKO

Model Number : H71H

Certification : CE/PED, API

Place of Origin : Made in China

MOQ : 1 piece

Price : By negotiation

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 350 tons per year

Delivery Time : 25 working days after deposit

Packaging Details : By export wooden cases

Structure : Piston

Seat Material : Hardface

Spring Material : Inconel

End Connection : Wafer

Face to face : JIS B2002

Feature : Short Pattern

Contact Now

Single Plate Spring Loaded Stainless Steel JIS Wafer Check Valve With Lift Type Design

Design Features

Investment casting

Low pressure drop

Highest degree of tightness

Low pressure drop, low friction

Seat: Metal seated.

Single Plate Spring Loaded Stainless Steel JIS Valve , Wafer Check Valve With Lift Type Design

Material List for JIS Lift Check Valve

NO. Part Name Material
1 Body WCB+13Cr SCS13
2 Disc WCB+13Cr SCS13
3 Spring 0Cr18Ni9 0Cr18Ni9

Dimensions:

DN 50 65 80 100 125 150 200 250 300 350 400 450 500
L 40 46 50 61 90 104 140 146 181 184 191 203 219
D 100 118 133 164 197 217 285 338 410 451 514 540 606
